A3 Super4 Hobbyeagle Flight Controller 6-Axis Gyro Stabilizer Full Set with Program Card for Fixed Wing RC Airplane FPV Aircraft Models (A3 Super4 Full Set)
Product details
| Management number | 216429635 | Release Date | 2026/04/19 | List Price | $24.80 | Model Number | 216429635 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Features: 32-bit MCU, high-precision 6-axis MEMS sensor, improved hardware and stable firmware provide more reliable performance. 6 flight modes and 6-position switching, including GYRO-OFF, NORMAL, LOCK, ANGLE, LEVEL and HOVER modes. User defined mode supported. PWM, PPM and multi-protocal serial digital receiver supported. Customizable output channels and 2 pass-through auxiliary channels. Dual aileron and dual elevator system, flying-wing (delta-wing) and V-tail supported. Remote master gain supported. Firmware upgradable and Programming Card supported. Serial Receiver Protocols Supported: PPM Receiver Futaba SBus (compatible with FrSky SBus, JETI SBus, RadioLink SBus, TBS SBus and WFLY WBus) Spektrum DSM2/X 1024 Satellite (Remote) Receiver Spektrum DSM2/X 2048 Satellite (Remote) Receiver Spektrum SRXL Multiplex SRXL / JR XBUS Mode B Graupner SUMD FlySky iBus JETI EXBus TBS/ELRS CRSF Specification: Main controller: 32-bit microprocessor Built-in sensors: High-precision MEMS 6-axis sensor Gyro range: ± 2000 dps Acceleration range: ± 4g PWM output: 800 ~ 2220uS, median 1500/1520uS, frequency 50Hz ~ 333Hz Working voltage:DC 4.8V ~ 8.4V Working temperature: -10℃ ~ 50℃ Dimensions: 43×27×14mm (L×W×H) Weight: 10g (without connecting cable) Package Included: 1 x A3 Super 4 Main Controller 1× Program Card 1×LED module 3 x Receiver Cable 1 x Data Cable 1 x Adapter 2 x Double-sided Tapes
- A3 Super 4 is a high-performance and functional 6-axis gyro and stabilizer designed for R/C airplanes. The hardware has been improved yet again based on the successful previous generation.
- PWM, PPM and multi-protocol serial digital receiver support and customizable output channels added to make the gyro more user-friendly and reliable.
- 6 flight modes and 6-position switching, including GYRO-OFF, NORMAL, LOCK, ANGLE, LEVEL and HOVER modes.
- Dual aileron and dual elevator system, flying-wing (delta-wing) and V-tail supported.
- Firmware upgradable and Programming Card supported.
| UPC | 741451880086 |
|---|---|
| Size | 43×27×14mm |
| Color | A3 Super4 Full Set |
| Theme | airplane |
| Set Name | Full Set |
| Brand Name | VilogaRC |
| Model Name | A3 Super 4 |
| Model Year | 2006 |
| Unit Count | 1.0 Count |
| Item Weight | 10 Grams |
| Manufacturer | Shenzhen Gangxin Sujiaozhipin Ltd. |
| Model Number | HEA3S4-FS |
| Power Source | Battery Powered |
| Material Type | Plastic |
| Item Type Name | RC Flight Gyroscopes |
| Operation Mode | Manual & Automatic |
| Item Dimensions | 1.7 x 1.06 x 0.55 inches |
| Number of Items | 1 |
| Toy Vehicle Form | Airplane |
| Additional Features | Portable |
| Included Components | A3 Super 4 Main Controller |
| Is Assembly Required | No |
| Age Range Description | Kid |
| Customer Package Type | FFP |
| Educational Objective | Learning RC Airplane Flight Control Systems and Programming |
| Are Batteries Required | No |
| Batteries are Included | No |
| Manufacturer Part Number | HEA3S4-FS |
| Manufacturer Maximum Age MONTHS | 960 |
| Manufacturer Minimum Age MONTHS | 168 |
